NAD PP 2e

Improved Energy Saving Phono Preamp

The PP 2e Phono Preamplifier offers superb performance in a clean and simple package for a very reasonable cost. Perfect for the budget-conscious audiophile, the PP 2e’s moving coil/moving magnet input selector provides different phono cartridge options. The PP 2e’s Auto Power Down feature saves energy by automatically powering the PP 2e to OFF when not in use.



  • Low noise, wide band MM & MC phono stage
  • Connect your turntable to almost all amplifiers and receivers
  • External 24 volt power supply
  • Gold plated input sockets
  • High quality components
  • LED power indicator

Specifications

MC

    • Input Impedance (R and C): 100 Ohm + 180pF
    • Gain at 1kHz: 60dB
    • Input Sensitivity (ref. 200mV output): 0.3mV
    • Signal to Noise Ratio: 78dB (A weighted, with cartridge connected)
    • Input Overload (20Hz/1kHz/20kHz): 0.8/9/84mV
    • Rated Distortion (THD 20Hz – 20kHz): <0.03%
    • RIAA Response Accuracy: ±0.3dB

MM

    • Input Impedance (R and C): 47 kilohm + 200pF
    • Gain at 1kHz: 35dB
    • Input sensitivity (ref. 200mV output): 2.5mV
    • Signal to Noise Ratio: 80dB (A weighted, with cartridge connected)
    • Input overload (20Hz/1kHz/20kHz): 10/102/950mV
    • Rated Distortion (THD 20Hz – 20kHz): <0.03%
    • RIAA response accuracy: ±0.3dB
